This map will be provided by purchasing the Airbox Kit on ASpecialParts.

Direct link: Shop aspecialparts.com

Best performance for Aprilia TuonoV4 R 1000cc (version EU, USA, 78Kw), model year 2011-2014, with UpMap, GRT map for stock engine, full exhaust Akrapovic and ASpecialParts Kit Airbox.

EXHAUST SYSTEM:

Full exhaust Akrapovic EVO2 (with balancer pipe).

ADDITIONAL SPECIFIC:

- Fueling adjusted to match the ASpecialParts Airbox Kit

- Lambda probe error disabled, it is possible to runplug connectors.

Quick tip: If not removed, lambda proble will continue working helping improving mileage a bit.

- Exhaust valve error disabled, it is possible to remove the valve from the motorcycle

- Pair system error disabled, it is possible to remove from the motorcycle.

- Rev limiter rised by 200rpm.

- General rideability improvement, throttle on-off reduction, engine brake reduction..

RIDE BY WIRE:

3 engine maps

- S is wet/turing: full power but tamed throttle, max engine brake

- T is road: full power and strong throttle, less engine brake

- R is race: full power and strong throttle, lesser engine brake

TECHNICAL DETAILS:

Typical gaing 3-4hp's on the whole power plot, plus a 8-10hp gain in last 1000rpm. compared to stock airbox + stock race map

INFO E-COMMERCE

How to get this calibration?

Thanks to your new UpMap device and the purchase of the Airbox kit on ASpecialParts you will get the coupon code^(*) to download this engine calibration.

^{(*) The coupon is unique and can only be used once.}
