T750 23 EU SCP FD BOANO 16-50

his map will be provided by purchasing the UpMap T800+ Kit on BoanoMoto.

Direct link: Shop boanomoto.com

Best performance for Honda Transalp 750 m.y. 2023, with UpMap, SC-Project full exhaust with baffle.

The maps dedicated to Boano Racing differ from the traditional ones for a better off-road throttle response with the map in Power Mode 1, the fuel and spark advance maps have been fine tuned for off-road use, together with the traction control maps refined thanks to Boano's experience.

Different configurations of rear and sproket front gear ratios are available for the best compromise on or off-road.

Final gear ratio modified: sprocket front 16 rear 50

Quick tip: use in combination only if the ratio has been changed as indicated.

(info: original gear ratio sprocket front 16 rear 45)

EXHAUST SYSTEM:

- SC-Project slip-on Rally Raid version (part number: H48A-100T)

- SC-Project slip-on X-Plorer II carbon version (part number: H448A-121C)

- SC-Project slip-on X-Plorer II titanium version (part number: H448A-121T)

- SC-Project header (part number: H48A-FS-SS)

- With baffle

ADDITIONAL SPECIFIC:

- Standard or Race air filter

(info: Aftermarket air filter allowed)

- Lambda sensor (closed loop) and error disabled

- Removed speed limiter in 5° and 6° gear

INFO E-COMMERCE

How to get this calibration?

Thanks to your new UpMap device and the purchase of the UpMap T800+ Kit on BoanoMoto you will get the coupon code (*) to download this engine calibration.

^{(*) The coupon is unique and can only be used once.}
